CCTV62

COMPACT SD/HD CCTV CAMERA
CCTV62

CCTV62 is a small-sized, radiation hardened, color camera with an auto focused x10 optical and x10 digital zoom. The camera features high quality focus and close-up capabilities. It is equipped with a lead front glass for improved radiation protection from the front.

Applications

  • For use in medium radiation areas with limited space available
  • Ideal to mount on a range of manipulator and tool systems

Benefits

  • Auto-focus and auto-iris
  • Small camera, diameter 62 mm
  • Equipped with lead front glass for improved protection
  • Available in SD/HD version

Specifications

Diameter
62 mm (2,44")
Length
219 mm (8,6")
Weight
4,4 kg, (9,11 lbs)
Housing material
Stainless steel EN 1.4301/EN 1.4436, AISI 304/AISI 316
Radiation tolerance (dose rate)
500 Gy/h (50 000 rad/h)
Radiation tolerance (total dose)
5 000 Gy (500 000 rad)
Radiation tolerance neutrons
Low
Maximum temperature
45°C (113°F)
Protection class
IP65
Zoom
x10 optical x10 digital giving x100
SD horizontal angle of view
35° (wide end), 5° (tele end)
HD horizontal angle of view
50° (wide end), 5° (tele end)
Minimum distance to object
5 mm (0,20")
Resolution SD version
720 TV-lines
Resolution HD version
720p
